Drive Axle for Forklift

Forklift Drive Axle - A forklift drive axle is a piece of equipment which is elastically connected to a vehicle framework utilizing a lift mast. The lift mast is connected to the drive axle and could be inclined round the drive axle's axial centerline. This is accomplished by no less than one tilting cylinder. Forward bearing parts combined with back bearing elements of a torque bearing system are responsible for fastening the vehicle and the drive axle framework. The drive axle can be pivoted round a swiveling axis oriented transversely and horizontally in the vicinity of the rear bearing components. The lift mast can likewise be inclined relative to the drive axle. The tilting cylinder is connected to the lift truck frame and the lift mast in an articulated fashion. This enables the tilting cylinder to be oriented almost parallel to a plane extending from the axial centerline and to the swiveling axis.

Model H35, H40, and H45 forklifts, that are produced by Linde AG in Aschaffenburg, Germany, have a mounted lift mast tilt on the vehicle framework itself. The drive axle is elastically attached to the frame of the lift truck by numerous various bearings. The drive axle contains a tubular axle body along with extension arms connected to it and extend rearwards. This particular kind of drive axle is elastically attached to the vehicle framework utilizing rear bearing elements on the extension arms together with forward bearing tools situated on the axle body. There are two rear and two front bearing devices. Each one is separated in the transverse direction of the lift truck from the other bearing machine in its respective pair.

The drive and braking torques of the drive axle are sustained through the rear bearing parts on the framework by the extension arms. The lift mast and the load produce the forces which are transmitted into the roadway or floor by the frame of the vehicle through the drive axle's anterior bearing elements. It is essential to be sure the elements of the drive axle are constructed in a firm enough manner so as to maintain immovability of the lift truck truck. The bearing elements can lessen slight road surface irregularities or bumps all through travel to a limited extent and give a bit smoother operation.
